Outboard Motor Rise & Fall Bracket Plastic

Description

Easy to use with quick release locking mechanism. Locking mechanism at both the fully raised and lowered position.

Suitable for outboard auxilary motors up to 8Hp.

All components made from marine grade stainless steel.

Spring loaded frame assists in raising the outboard to the UP position.

Dimensions
Height (oa) – 460mm
Vertical travel – 370mm

Plastic Mounting Pad
210mm (w widest) x 170mm (w skinniest) x 265mm (h)

Mounting Holes
94mm (w) x 126mm (h) x 157 (diag)

Retractable Outboard Motor Bracket
8hp Max
Stainless Steel with Plastic Motor Pad
